C625 is a durable, direct-lighting recessed luminaire that impresses with its high luminous efficacy and energy efficiency. This modular luminaire is highly versatile and can be integrated into almost all metal ceiling systems with panel dimensions larger than 575 × 575 mm. As a lighting and ceiling manufacturer, we can also integrate the luminaire into our metal ceilings ready to plug in, thereby providing a comprehensive solution from a single source.
C625 light cassette
Dimensions
Luminaire:
Overall size: 560 x 560 mm
Cover: 509 x 509 mm
Metal panel:
Minimum size: 575 x 575 mm
Cut-out: 500 x 500 mm
Material and surface
Housing: aluminium
Luminaire cover: micro-prismatic
Luminaire details
Light colour: 3000 K, 4000 K, 5000 K, Tunable White on request
Luminous flux: 4225.60 lm, luminous flux up to 12000 lm on request
Glare control: UGR19
Power supply: 230V/50 Hz
Protection type: IP 40
Protection class: I
