OMEGA 40 lighting channel system

Elegant accentuation with the lighting LINE

OMEGA 40 is a lighting channel system with LED technology featuring a versatile range of uses. With a channel width of only 40 mm, the lighting line is the perfect solution for many architectural applications and it emphasises architectural geometries in an elegant way. OMEGA 40 is based on a stable basic profile with lengths of up to 6 m.

  • System can be combined with rectangular metal panels from durlum.
  • System complemented by suspension and connector systems
  • Endless laying possible in gypsum.

Technical Information

Lighting channel

W: 40 mm
H: 73 mm
Surface: anodised aluminium, powder-coated on request


PMMA opal or microprismatic for UGR< 19 applications

Luminaire details

Light colour: 3000 K, 4000 K, CRI > 80
Luminaire output: 3796 lm/m (3000 K), 3968 lm/m (4000 K)
Dimmability: DALI dimmable
Driver: integrated
Power supply: 230 V/50 Hz
Protection degree: IP 20
Protection class: I
